CS5203-1 - 3.0 A Adjustable Linear Regulator

ON Semiconductor

📥 Download Datasheet

CS5203-1 Datasheet Preview — Preview of CS5203-1 PDF

Datasheet Details

Part number	CS5203-1
Manufacturer	ON Semiconductor
File Size	274.11 KB
Description	3.0 A Adjustable Linear Regulator
Datasheet	CS5203-1_ONSemiconductor.pdf

CS5203-1 Product details

Description

Package Pin Number TO 220 3 1 2 3 D2PAK 3 1 2 3 Pin Symbol Adj VOUT VIN Function Adjust pin (low side of the internal reference). 1 VIN VOUT Output Current Limit Thermal Shutdown Bandgap Reference + Error Amplifier Adj Figure 2. Block Diagram TYPICAL PERFORMANCE CHARACTERISTICS 1.20 Reference Voltage Deviation (%) 1.15 Dropout Voltage (V) 1.10 1.05 1.00 0.95 0.90 0.85 0.80

Features

Output Current to 3.0 A.
Output Accuracy to ±1.5% Over Temperature.
Dropout Voltage (typical) 1.2 V @ 3.0 A.
Fast Transient Response.
Fault Protection.
Current Limit.
Thermal Shutdown 5.0 V VIN VOUT http://onsemi. com TO.
220.
3 T SUFFIX CASE 221A 1 Tab = VOUT Pin 1. Adj 2. VOUT 3. VIN 2 3 D2PAK.
3 DP SUFFIX CASE 418AB 12 3.
