BZX84C20ET1G - Zener Voltage Regulators

Download the BZX84C20ET1G datasheet PDF. This datasheet also covers the BZX84C2V4ET1G variant, as both devices belong to the same zener voltage regulators family and are provided as variant models within a single manufacturer datasheet.

Features

  • 250 mW Rating on FR.
  • 4 or FR.
  • 5 Board.
  • Zener Breakdown Voltage Range.
  • 2.4 V to 75 V.
  • Package Designed for Optimal Automated Board Assembly.
  • Small Package Size for High Density.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (BZX84C2V4ET1G-ONSemiconductor.pdf) that lists specifications for multiple related part numbers.
