BZX55C6V2RL

The BZX55C6V2RL is 500 mW DO-35 Hermetically designed by ON Semiconductor.

Product Overview

ON Semiconductor

📥 Download Datasheet

BZX55C6V2RL 500 mW DO-35 Hermetically by ON Semiconductor - Datasheet Preview — Datasheet preview – BZX55C6V2RL

Datasheet Details

Part number	BZX55C6V2RL, BZX55C2V4RL
Manufacturer	ON Semiconductor
File Size	243.22 KB
Description	500 mW DO-35 Hermetically
Datasheet	BZX55C2V4RL-ONSemiconductor.pdf
Note	This datasheet PDF includes multiple part numbers: BZX55C6V2RL, BZX55C2V4RL. Please refer to the document for exact specifications by model.
Additional preview pages of the BZX55C6V2RL datasheet.

Product details

Features

Zener Voltage Range.
2.4 V to 33 V.
ESD Rating of Class 3 (>16 KV) per Human Body Model.
DO.
204AH (DO.
35) Package.
Smaller than Conventional DO.
204AA Package.
Double Slug Type Construction.
Metallurgical Bonded Construction Mechanical Characteristics: CASE: Double slug type, hermetically sealed glass FINISH: All external surfaces are corrosion resistant and leads are readily solderable.
