MBRS330T3 - N-Channel FET Synchronous Buck Regulator Controller

National Semiconductor

The MBRS330T3 by National Semiconductor is a N-Channel FET Synchronous Buck Regulator Controller. Below is the official datasheet preview.

📥 Download Datasheet

MBRS330T3 N-Channel FET Synchronous Buck Regulator Controller by National Semiconductor - Datasheet Preview — Official preview page of the **MBRS330T3** N-Channel FET Synchronous Buck Regulator Controller datasheet (National Semiconductor).

Datasheet Details

Part number	MBRS330T3
Manufacturer	National Semiconductor
File Size	602.18 KB
Description	N-Channel FET Synchronous Buck Regulator Controller
Datasheet	MBRS330T3_NationalSemiconductor.pdf
Additional preview pages of the MBRS330T3 datasheet.

MBRS330T3 Product details

Description

The LM2727 and LM2737 are high-speed, synchronous, switching regulator controllers.

Features

The LM2737 and LM2737 operate from a low-current 5V bias and can convert from a 2.2V to 16V power rail. Both parts utilize a fixedfrequency, voltage-mode, PWM control architecture and the switching frequency is adjustable from 50kHz to 2MHz by adjusting the value of an external resistor. Current limit is achieved by monitoring the voltage drop across the onresistance of the low-side MOSFET, which enhances low duty-cycle operation. The wide range of operating frequencies gives the power supply d.
