TEA6322T - Sound fader control circuit

Description

The sound fader control circuit TEA6322T is an I2C-bus controlled stereo preamplifier for car radio hi-fi sound applications.

MAX.

+20 +15 +12 V UNIT mA mV dB dB dB dB dB dB dB dB ORDERING INFORMATION PACKAGE TYP

Features

  • Source selector for three stereo and one differential stereo input for remote sources.
  • The differential stereo input works optional as a fourth stereo input and the common mode pin can be used as well as an additional mono input.
  • Interface for noise reduction circuits.
  • Interface for external equalizer.
  • Volume, balance and fader control.
  • Output at volume I for external booster.
  • Special loudness characteristic automatically controlled.
