BC868PA, BC868 - NPN medium power transistor

BC868PA Description

BCP68; BC868; BC68PA 20 V, 2 A NPN medium power transistors Rev.8 * 18 October 2011 Product data sheet 1.Product profile 1.1 General des.
NPN medium power transistor series in Surface-Mounted Device (SMD) plastic packages.

BC868PA Features

* High current
* Two current gain selections
* High power dissipation capability
* Exposed heatsink for excellent thermal and electrical conductivity (SOT89, SOT1061)
* Leadless very small SMD plastic package with medium power capability (SOT1061)
* AEC-Q101 qualified 1.3 Ap

BC868PA Applications

* Linear voltage regulators
* Low-side switches
* Battery-driven devices
* Power management
* MOSFET drivers
* Amplifiers 1.4 Quick reference data Table 2. Symbol VCEO IC ICM Quick reference data Parameter Conditions collector-emitter voltage open base collector curre

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: BC868PA, BC868. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
BC868PA, BC868
Manufacturer
NXP ↗
File Size
388.85 KB
Datasheet
BC868_PhilipsSemiconductors.pdf
Description
NPN medium power transistor
Note
This datasheet PDF includes multiple part numbers: BC868PA, BC868.
Please refer to the document for exact specifications by model.
