Datasheet Details
Part number:
UPD44325094, UPD44325084
Manufacturer:
NEC
File Size:
391.77 KB
Description:
36m-bit qdrii sram.
Note:
This datasheet PDF includes multiple part numbers: UPD44325094, UPD44325084.
Please refer to the document for exact specifications by model.
UPD44325094, UPD44325084, 36M-BIT QDRII SRAM
The µPD44325084 is a 4,194,304-word by 8-bit, the µPD44325094 is a 4,194,304-word by 9-bit, the µPD44325184 is a 2,097,152-word by 18-bit and the µPD44325364 is a 1,048,576-word by 36-bit synchronous quad data rate static RAM fabricated with advanced CMOS technology using full CMOS six-transistor me
UPD44325094 Features
* 1.8 ± 0.1 V power supply and HSTL I/O
* DLL circuitry for wide output data valid window and future frequency scaling
* Separate independent read and write data ports with concurrent transactions
* 100% bus utilization DDR READ and WRITE operation
* Four-tick
