DLW31SN102SQ2 - Chip Common Mode Choke Coil

Download the DLW31SN102SQ2 datasheet PDF. This datasheet also covers the DLW21SN670SQ2 variant, as both devices belong to the same chip common mode choke coil family and are provided as variant models within a single manufacturer datasheet.

Features

  • Classification Structure Part Number Comments.
  • Low profile, small size, suitable for mobile equipments.
  • Tight terminal pitch enables high density layout.
  • Ultra high cut-off frequency and its matching to line impedance enables good transmission of high speed signal.
  • Ultra high self resonance frequency enables high cut-off frequency.
  • Its matching to line impedance enables good transmission of high speed signal.
  • Low profile, small size, suitable for mobile equ.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (DLW21SN670SQ2-Murata.pdf) that lists specifications for multiple related part numbers.
