MC146823 - CMOS Parallel Interface

Product Overview

Motorola Semiconductor

📥 Download Datasheet

MC146823 CMOS Parallel Interface by Motorola Semiconductor - Datasheet Preview — Datasheet preview – MC146823

Datasheet Details

Part number	MC146823
Manufacturer	Motorola Semiconductor
File Size	614.13 KB
Description	CMOS Parallel Interface
Datasheet	MC146823_MotorolaSemiconductor.pdf
Additional preview pages of the MC146823 datasheet.

Product details

Features

include:.
24 Individually Programmed 1/0 Pins.
MOTEL Circuit for Bus Compatibility with Many Microprocessors.
Multiplexed Bus Compatibility with: MC146805E2, MC6801, MC6803, and Competitive Microprocessors.
Data Direction Registers for Ports A, B, and C.
Four Port CliO Pins May Be Used as Control Lines for: Four Interrupt Inputs Input Byte Latch Output Pulse Handshake Activity.
15 Registers Addressed as Memory Locations.
Handshake C.
