SA14A - MOSORB ZENER OVERVOLTAGE TRANSIENT SUPPRESSORS

Motorola Inc

📥 Download Datasheet

SA14A Datasheet Preview — Preview of SA14A PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	SA14A
Manufacturer	Motorola Inc
File Size	50.68 KB
Description	MOSORB ZENER OVERVOLTAGE TRANSIENT SUPPRESSORS
Datasheet	SA14A_MotorolaInc.pdf

SA14A Product details

Features

Stand-off Zener Voltage Range.
5 to 170 V.
Peak Power.
500 Watts @ 1 ms.
Maximum Clamp Voltage @ Peak Pulse Current.
Low Leakage < 1 µA Above 8.5 Volts.
Maximum Temperature Coefficient Specified.
Response Time is Typically Less than 1 ns Mechanical Characteristics: CASE: Void-free, transfer-molded, thermosetting plastic FINISH: All external surfaces are corrosion resistant and leads are readily solderable.
