M38063E6-XXXGP - SINGLE-CHIP 8-BIT CMOS MICROCOMPUTER

Download the M38063E6-XXXGP datasheet PDF. This datasheet also covers the M3806x variant, as both devices belong to the same single-chip 8-bit cmos microcomputer family and are provided as variant models within a single manufacturer datasheet.

Description

The M3806x group is made up of 8-bit microcomputers based on the MELPS 740 core.

The M3806x group is designed for controlling systems that reqllire analog signal processing and include two serial 1/0 functions, A-D converters, and D-A converters.

Features

  • Basic machine-language instructions.
  • 71.
  • Instruction execution time.
  • 0.5J. ls (shortest instruction at 8MHz oscillation frequency).
  • Memory size ROM 4K to 32K bytes RAM.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (M3806x-Mitsubishi.pdf) that lists specifications for multiple related part numbers.
