M63802KP - (M63802xx) 7-UNIT 300mA TRANSISTOR ARRAY

Product Overview

Mitsubishi Electric

Part number	M63802KP
Manufacturer	Mitsubishi Electric
File Size	81.50 KB
Description	(M63802xx) 7-UNIT 300mA TRANSISTOR ARRAY
Datasheet	M63802KP Datasheet
Note	This datasheet PDF includes multiple part numbers: M63802KP, M63802FP. Please refer to the document for exact specifications by model.
Additional preview pages of the M63802KP datasheet.

M63802P, M63802FP, M63802GP and M63802KP are seven-circuit Singe transistor arrays.

Four package configurations (P, FP, GP and KP) q Medium breakdown voltage (BVCEO ≥ 35V) q Synchronizing current (IC(max) = 300mA) q With zener diodes q Low output saturation voltage q Wide operating temperature range (Ta=.
40 to +85 °C) q GND 8 NC 16P4(P) 16P2N-A(FP) 16P2S-A(GP) Package type 16P2Z-A(KP) NC : No connection.
