MITSUBISHI Nch POWER MOSFET
FS3SM-16A
HIGH-SPEED SWITCHING USE
FS3SM-16A
OUTLINE DRAWING
15.9MAX.
Dimensions in mm 4.5 1.5 r
5.0 2
2
19.5MIN.
4
20.0
φ 3.2
4.4
1.0 q 5.45 w e 5.45
0.6
2.8
4 wr q GATE w DRAIN e SOURCE r DRAIN e
q
¡VDSS ................................................................................ 800V ¡rDS (ON) (MAX) ................................................................ 3.3Ω ¡ID ............................................................................................ 3A
TO-3P
APPLICATION SMPS, DC-DC Converter, battery charger, power supply of printer, copier, HDD, FDD, TV, VCR, personal computer etc.
