M28945-33 - G.Shdsl Transceiver

Product Overview

Datasheet Details

Part number	M28945-33
Manufacturer	Mindspeed Technologies
File Size	3.43 MB
Description	G.Shdsl Transceiver
Datasheet	M28945-33 Datasheet
Note	This datasheet PDF includes multiple part numbers: M28945-33, M28927. Please refer to the document for exact specifications by model.
Additional preview pages of the M28945-33 datasheet.

Product details

Description

DSP/Framer DSP/Framer AFE/Line Driver Package 176-pin LQFP 48-pin ETQFP 13 × 13 mm FPBGA 48-pin ETQFP 6 x 6 mm 48-pin ETQFP Ambient Temperature Range 40 °C to +85 °C 40 °C to +85 °C 40 °C to +85 °C Revision History Revision A B C D A Level Advance Advance Advance Advance Preliminary Date June 2000 August 2000 January 2001 January 2001 May 2001 Initial release.Description Added copyright information to footer on front page.No technical information was changed.Up

Features

Highly integrated solution including framer, microprocessor, ROM/RAM, frequency synthesizer, DSP, AFE, and line driver.
Multimode operation including:.
ITU-T G. shdsl including EPAP modes (ITU-T G.991.2).
ITU-T G. handshake (ITU-T G.994.1).
HDSL2 (ANSI T1.418).
SDSL/2B1Q (AutoBaud).
HDSL (ITU-T G.991.1, ETSI 101 135 and ANSI TR-28).
Proprietary/Extended Reach (ANSI spectrum management for loop transmission systems).
