IT124 Datasheet (Micross) - General Purpose

IT124, General Purpose

IT124 MONOLITHIC DUAL NPN TRANSISTOR Linear Systems replaces discontinued Intersil IT124 The IT124 is a monolithic pair of Super-Beta NPN transistors mounted in a single P-DIP package.

The monolithic dual chip design reduces parasitics and gives better performance while ensuring extremely tight matching.

The IT124 is a direct replacement for discontinued Intersil IT124.

The 8 Pin P-DIP provides ease of manufacturing, and the symmetrical pinout prevents improper orientation.

(See Packaging Infor

IT124 Features

* FEATURES Direct Replacement for INTERSIL IT124 HIGH GAIN LOW OUTPUT CAPACITANCE VBE tracking ABSOLUTE MAXIMUM RATINGS 1 @ 25°C (unless otherwise noted) Maximum Temperatures Storage Temperature Operating Junction Temperature Maximum Power Dissipation Continuous Power Dissipa
