LX5506M - InGaP HBT 4.5 - 6GHz Power Amplifier

Microsemi Corporation

Datasheet Details

Part number	LX5506M
Manufacturer	Microsemi Corporation
File Size	97.21 KB
Description	InGaP HBT 4.5 - 6GHz Power Amplifier
Datasheet	LX5506M_MicrosemiCorporation.pdf

KEY

Broadband 4.9-5.9GHz Operation Advanced InGaP HBT Single-Polarity 3.3V Supply Power Gain ~ 30dB at 5.25GHz Power Gain > ~28dB Across 4.95.9GHz EVM ~ -30dB at Pout=+17dBm at 5.25GHz EVM ~ -30dB at Pout=+18dBm at 5.85GHz Total Current ~140mA for Pout = +17dBm at 5.25GHz (For High Duty Cycle of 90%) Maximum Linear Power ~ +22dBm for OFDM Mask Compliance Maximum Linear Efficiency ~ 20% On-chip Output Powe.
