PIC16F873 - 8-Bit CMOS FLASH Microcontrollers

Datasheet Summary

Features

  • High performance RISC CPU.
  • Only 35 single word instructions to learn.
  • All single cycle instructions except for program branches which are two cycle.
  • Operating speed: DC - 20 MHz clock input DC - 200 ns instruction cycle.
  • Up to 8K x 14 words of FLASH Program Memory, Up to 368 x 8 bytes of Data Memory (RAM) Up to 256 x 8 bytes of EEPROM Data Memory.
  • Pinout compatible to the PIC16C73B/74B/76/77.
  • Interrupt capability (up to 14 sources).

📥 Download Datasheet

Datasheet preview – PIC16F873

Datasheet Details

Part number PIC16F873
Manufacturer Microchip
File Size 1.97 MB
Description 8-Bit CMOS FLASH Microcontrollers
