24C320, 24C320-EP 32K 5.0V SPI Bus Serial EEPROM

24C320 Description

25C320 32K 5.0V SPI™ Bus Serial EEPROM .
The Microchip Technology Inc.

24C320 Features

* SPI modes 0,0 and 1,1
* 3.0 MHz Clock Rate
* Single 5V Supply
* Low Power CMOS Technology - Max Write Current: 5 mA - Read Current: 1.0 mA at 5.5V, 3MHz - Standby Current: 1 µA typical
* 4096 x 8 Organization
* 32 Byte Page
* Sequen

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: 24C320, 24C320-EP. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
24C320, 24C320-EP
Manufacturer
Microchip ↗
File Size
86.05 KB
Datasheet
24C320-EP_MicrochipTechnology.pdf
Description
32K 5.0V SPI Bus Serial EEPROM
Note
This datasheet PDF includes multiple part numbers: 24C320, 24C320-EP.
Please refer to the document for exact specifications by model.
