MIC5012 - Dual High- or Low-Side MOSFET Driver Not Recommended for New Designs

Micrel Semiconductor

📥 Download Datasheet

MIC5012 Datasheet Preview — Preview of MIC5012 PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	MIC5012
Manufacturer	Micrel Semiconductor
File Size	103.65 KB
Description	Dual High- or Low-Side MOSFET Driver Not Recommended for New Designs
Datasheet	MIC5012-MicrelSemiconductor.pdf

MIC5012 Product details

Description

The MIC5012 is the dual member of the Micrel MIC501X driver family.

Features

4.75V to 32V operation.
2 independent drivers; implements high and low side drivers.
Less than 1µA standby current in the “off” state per channel.
Available in small outline SOIC packages.
Internal charge pump to drive the gate of an N-channel power FET above supply.
Internal zener clamp for gate protection.
Minimum external parts count.
Can be used to boost drive to low-side power FETs operating on logic supplies.
