MAX4138 - 1-Input/4-Output Video Distribution Amplifiers

Description

The MAX4135/MAX4136 are 1-input/6-output voltagefeedback amplifiers that combine high speed with fast switching for video distribution applications.

The MAX4135 is internally set for a closed-loop gain of 2V/V, while the MAX4136 can be externally set for gains of 2V/V or greater.

Features

  • o Fixed Gain of 2V/V (MAX4135) External Gain Set (MAX4136) o High Speed: 185MHz -3dB Bandwidth (MAX4135) 140MHz -3dB Bandwidth (MAX4136) 1000V/µs Slew Rate o High Full-Power Bandwidths (VOUT = 2Vp-p): 185MHz (MAX4135) 140MHz (MAX4136) o 0.1dB Gain Flatness to 40MHz o Low Differential Gain/Phase Error: 0.10%/0.02° o High-Impedance Output Disable MAX4135/MAX4136 ______________Ordering Information PART TEMP. RANGE -40°C to +85°C -40°C to +85°C PIN-.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
MAX4130 Rail-to-Rail I/O Op Amps Maxim Integrated
MAX4131 Rail-to-Rail I/O Op Amps Maxim Integrated
MAX4132 Rail-to-Rail I/O Op Amps Maxim Integrated
MAX4133 Rail-to-Rail I/O Op Amps Maxim Integrated
MAX4134 Rail-to-Rail I/O Op Amps Maxim Integrated

Other Datasheets by Maxim Integrated (Analog Devices)

Part Number Description
MAX4135 1-Input/4-Output Video Distribution Amplifiers
MAX4136 1-Input/4-Output Video Distribution Amplifiers
MAX4137 1-Input/6-Output Video Distribution Amplifiers
MAX410 Single/Dual/Quad / 28MHz / Low-Noise / Low-Voltage / Precision Op Amps
MAX4100 500MHz / Low-Power Op Amps

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
19-1092; Rev 0; 6/96 KIT ATION EVALU BLE A IL A V A 1-Input/6-Output Video Distribution Amplifiers _______________General Description The MAX4135/MAX4136 are 1-input/6-output voltagefeedback amplifiers that combine high speed with fast switching for video distribution applications. The MAX4135 is internally set for a closed-loop gain of 2V/V, while the MAX4136 can be externally set for gains of 2V/V or greater. The MAX4135 achieves a -3dB bandwidth of 185MHz, with 0.1dB gain flatness to 40MHz. The MAX4136’s -3dB bandwidth is 140MHz. Both devices deliver a 1000V/µs slew rate, as well as exceptional full-power bandwidths of 185MHz and 140MHz, respectively.
