MAX77960 - USB-C Buck-Boost Charger

Product Overview

Maxim Integrated

Datasheet Details

Part number	MAX77960
Manufacturer	Maxim Integrated
File Size	949.80 KB
Description	USB-C Buck-Boost Charger
Datasheet	MAX77960 Datasheet
Additional preview pages of the MAX77960 datasheet.

Product details

Description

The MAX77960/MAX77961 are high-performance wideinput 3A (MAX77960)/6A (MAX77961) buck-boost chargers with Smart Power Selector™ and operate as a reverse buck converter without an additional inductor, allowing the ICs to power USB on-the-go (OTG) accessories.

Features

3.5V to 25.4V Input Operating Range, 30VDC Withstand.
97% Peak Efficiency for 2S Battery at 9VIN/7.4VOUT/1.5AOUT.
97% Peak Efficiency for 3S Battery at 15VIN/12.6VOUT/2AOUT.
MAX77960.
100mA to 3.15A Programmable Input Current Limit.
100mA to 3A Programmable Constant Current Charge.
MAX77961.
100mA to 6.3A Programmable Input Current Limit.
100mA to 6A Programmable Constant Current Charge.
Remote Differential Voltage Sensing.
