MAX14983E - Enhanced 1:2 VGA Mux

Product Overview

Maxim Integrated

Datasheet Details

Part number	MAX14983E
Manufacturer	Maxim Integrated
File Size	759.91 KB
Description	Enhanced 1:2 VGA Mux
Datasheet	MAX14983E Datasheet
Additional preview pages of the MAX14983E datasheet.

Product details

Description

The MAX14983E integrates high-bandwidth analog switches, level-translating buffers, and 5V power switches to implement a complete 1:2 multiplexer for VGA monitors.

Features

a simple power interface that operates with a single +5V supply input. Two integrated power switches with current limiting and reverse-current protection pass the +5V supply to external loads with minimal voltage drop. The horizontal and vertical synchronization (HSYNC/ VSYNC) buffers shift logic levels to support +2.5V to +5.0V CMOS or TTL-compatible graphics controllers while meeting the VESA drive capability requirement of ±8mA. An internal 2.5V regulator translates the DDC voltage levels to.
