MPQ6528 - H-Bridge Gate Driver

Name: MPQ6528
SKU: MPQ6528-1532241

MPS

The MPQ6528 by MPS is a H-Bridge Gate Driver. Below is the official datasheet preview.

📥 Download Datasheet

MPQ6528 H-Bridge Gate Driver by MPS - Datasheet Preview — Official preview page of the **MPQ6528** H-Bridge Gate Driver datasheet (MPS).

Datasheet Details

Part number	MPQ6528
Manufacturer	MPS
File Size	594.81 KB
Description	H-Bridge Gate Driver
Datasheet	MPQ6528-MPS.pdf
Additional preview pages of the MPQ6528 datasheet.

MPQ6528 Product details

Description

The MPQ6528 is an H-bridge gate driver IC that can drive two half-bridges with four N-channel power MOSFETs across a wide 5V to 60V input voltage (VIN) range.

Features

include configurable short-circuit protection (SCP), over-current protection (OVP), under-voltage lockout (UVLO) protection, adjustable dead time (DT) control, and thermal shutdown. The MPQ6528 is available in a QFN-28 (4mmx5mm) package with an exposed thermal pad. MPQ6528 5V to 60V, H-Bridge Gate Driver, AEC-Q100 Qualified.
