MP3384 - 4-String White LED Driver

Product Overview

MPS

📥 Download Datasheet

MP3384 4-String White LED Driver by MPS - Datasheet Preview — Datasheet preview – MP3384

Datasheet Details

Part number	MP3384
Manufacturer	MPS
File Size	353.97 KB
Description	4-String White LED Driver
Datasheet	MP3384 Datasheet
Additional preview pages of the MP3384 datasheet.

Product details

Description

The MP3384 is a step-up converter with 4-channel current sources designed for driving the white LED arrays for large size LCD panel backlighting applications.

Features

High Efficiency and Small Size.
4.5V to 25V Input Voltage Range.
50V Maximum Step-up Voltage.
Balanced Driver for 4 Strings of WLED.
2.5% Current Matching Accuracy Between Strings.
Selectable Switching Frequency: 1.25MHz or 625kHz.
PWM Dimming.
Programmable Over-voltage Protection.
Under Voltage Lockout.
Open and Short LED Protection.
Thermal Shutdown.
Small 16-pin QFN (3mm x 3mm).
