MP2361 - 1.4MHz Step-Down Converter

Product Overview

MPS

📥 Download Datasheet

MP2361 1.4MHz Step-Down Converter by MPS - Datasheet Preview — Datasheet preview – MP2361

Datasheet Details

Part number	MP2361
Manufacturer	MPS
File Size	484.41 KB
Description	1.4MHz Step-Down Converter
Datasheet	MP2361 Datasheet
Additional preview pages of the MP2361 datasheet.

Product details

Description

The MP2361 is a monolithic step-down switch mode converter with a built-in internal power MOSFET.

Features

2A Output Current.
0.18Ω Internal Power MOSFET Switch.
Stable with Low ESR Output Ceramic Capacitors.
90% Efficiency.
20μA Shutdown Mode.
Fixed 1.4MHz Frequency.
Thermal Shutdown.
Cycle-by-Cycle Over Current Protection.
Wide 4.75V to 23V Operating Input Range.
Output Adjustable from 0.92V to 16V.
Programmable Under Voltage Lockout.
Available in QFN10, MSOP10, MSOP10E, and SOIC8 Packages.
