MP1583DN, MP1583 - 385KHz Step-Down Converter

MPS

The MP1583DN by MPS is a 385KHz Step-Down Converter. Below is the official datasheet preview.

📥 Download Datasheet

MP1583DN 385KHz Step-Down Converter by MPS - Datasheet Preview — Official preview page of the MP1583DN 385KHz Step-Down Converter datasheet (MPS).

Datasheet Details

Part number	MP1583DN, MP1583
Manufacturer	MPS
File Size	346.15 KB
Description	385KHz Step-Down Converter
Datasheet	MP1583-MPS.pdf
Note	This datasheet PDF includes multiple part numbers: MP1583DN, MP1583. Please refer to the document for exact specifications by model.
Additional preview pages of the MP1583DN datasheet.

MP1583DN Product details

Description

The MP1583 is a step-down regulator with a built-in internal Power MOSFET.

Features

3A Output Current.
Programmable Soft-Start.
100mΩ Internal Power MOSFET Switch.
Stable with Low ESR Output Ceramic Capacitors.
Up to 95% Efficiency.
20μA Shutdown Mode.
Fixed 385KHz Frequency.
Thermal Shutdown.
Cycle-by-Cycle Over Current Protection.
Wide 4.75V to 23V Operating Input Range.
Output Adjustable from 1.22V to 21V.
Under-Voltage Lockout.
