MP100 - Offline Inductor-less Regulator

MPS

The MP100 by MPS is a Offline Inductor-less Regulator. Below is the official datasheet preview.

📥 Download Datasheet

MP100 Offline Inductor-less Regulator by MPS - Datasheet Preview — Official preview page of the MP100 Offline Inductor-less Regulator datasheet (MPS).

Datasheet Details

Part number	MP100
Manufacturer	MPS
File Size	432.68 KB
Description	Offline Inductor-less Regulator
Datasheet	MP100-MPS.pdf
Additional preview pages of the MP100 datasheet.

MP100 Product details

Description

The MP100 is a compact, inductor-less, goodefficiency, off-line regulator.

Features

Universal AC Input (85VAC-to-305VAC).
Smart Control to Maximize Efficiency.
Adjustable Output Voltage from 1.5V to 15V.
Low Component Count and Cost.
Thermal Shutdown Protection.
Short-Circuit Protection.
Provide Power-Good Signal.
No Bulk Capacitor Required.
