PWB2405D-1W5, PWB2415MD-1W5 DUAL/SINGLE OUTPUT DIP DC-DC CONVERTER

MORNSUN

Description

PWA_(M)D-1W5&PWB_(M)D-1W5 Series 1.5W, WIDE INPUT, ISOLATED & REGULATED DUAL/SINGLE OUTPUT DIP DC-DC CONVERTER multi-country patent protection RoHS FE.

📥 Download Datasheet

PWB2405D-1W5 Datasheet Preview — This datasheet PDF includes multiple part numbers: PWB2405D-1W5, PWB2415MD-1W5. Please refer to the document for exact specifications by model.

Datasheet Specifications

Part number: PWB2405D-1W5, PWB2415MD-1W5
Manufacturer: MORNSUN
File Size: 126.29 KB
Datasheet: PWB2415MD-1W5_MORNSUN.pdf
Description: DUAL/SINGLE OUTPUT DIP DC-DC CONVERTER
Note: This datasheet PDF includes multiple part numbers: PWB2405D-1W5, PWB2415MD-1W5.
Please refer to the document for exact specifications by model.

Features

* Wide input voltage(4:1) Operating Temperature: -40°C to +85°C 1500VDC Input/Output Isolation Short Circuit Protection(automatic recovery) Internal SMD construction No external component required No Heat Sink Required Industry Standard Pinout Five-sided shielding package(PWA/B_MD) MTBF>1,000,000 hour

Applications

* The PWA_(M)D-1W5&PWB_(M)D-1W5 Series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board. These products apply to: 1) Where the voltage of the input power supply is wi
