nanoSMDC020F, nanoSMDC010F surface mount overcurrent protection

nanoSMDC020F Description

nanoSMDC Series Surface Mount PTC Datasheet RoHS .
The nanoSMDC series provides surface mount overcurrent protection for applications where space is at a premium and resettable protection is desired.

nanoSMDC020F Features

* & Benefits
* Broadest range of resettable devices available in industry
* Low resistance
* Small 1206 footprint
* Fast time-to-trip

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: nanoSMDC020F, nanoSMDC010F. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
nanoSMDC020F, nanoSMDC010F
Manufacturer
Littelfuse ↗
File Size
412.38 KB
Datasheet
nanoSMDC010F-Littelfuse.pdf
Description
surface mount overcurrent protection
Note
This datasheet PDF includes multiple part numbers: nanoSMDC020F, nanoSMDC010F.
Please refer to the document for exact specifications by model.
