DSS2x81-0045B
45 V, 2 x 80 A High-Performance Schottky Diode
Low Loss and Soft Recovery Parallel Legs
Features
■ Very low VF ■ Extremely low switching
losses ■ High reliability circuit
operation
Diode Datasheet
RoHS
■ Low-noise switching ■ UL recognized as an
Electrically Isolated Semiconductor Device (file number E72873)
Pinout Diagram SOT-227B (miniBLOC™)
backside: isolated
1
4
Benefits
■ Low voltage peaks for reduced protection circuits
■ Improved thermal behavior
■ Longer lifetime of the system
Applications
■ Rectifiers in Switch Mode Power Supplies (SMPS)
■ Free wheeling diode in low voltage converters
1
4
2
3
2
3
1: Cathode; 2: Anode; 3: Anode; 4: Cathode
Package SOT-227B (miniBLOC)
■ Isolation voltage: 3000 V ~ ■ RoHS compliant ■ Epoxy meets UL 94V-0 ■ Industry standa
DSS2x81-0045B Datasheet
