LTC3114-1 - 1A Synchronous Buck-Boost DC/DC Converter

📥 Download Datasheet

Preview of LTC3114-1 PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number LTC3114-1
Manufacturer Linear
File Size 1.58 MB
Description 1A Synchronous Buck-Boost DC/DC Converter
Datasheet download datasheet LTC3114-1-Linear.pdf

LTC3114-1 Product details

Description

n Regulates VOUT Above, Below or Equal to VIN n Single Inductor n Wide VIN Range: 2.2V to 40V n Wide VOUT Range: 2.7V to 40V n 1A Output Current in Buck Mode n 0.5A Output Current, VIN = 3.6V, VOUT = 5V n Programmable Average Output Current n Up to 96% Efficiency n Burst Mode® Operation, 30µA No-Load IQ n Current Mode Control n 1.2MHz Ultralow Noise PWM n Accurate RUN Pin Threshold n Thermally Enhanced, 16-lead 3mm × 5mm DFN and TSSOP Packages n AEC-Q100 Qualified for Automotive Applications AP
