LT1765-2.5, LT1765 - 1.25MHz Step-Down Switching Regulator

Linear Technology

Datasheet Details

Part number	LT1765-2.5, LT1765
Manufacturer	Linear Technology
File Size	203.12 KB
Description	1.25MHz Step-Down Switching Regulator
Datasheet	LT1765-LinearTechnology.pdf
Note	This datasheet PDF includes multiple part numbers: LT1765-2.5, LT1765. Please refer to the document for exact specifications by model.

The LT®1765 is a 1.25MHz monolithic buck switching regulator.

n 3A Switch in a Thermally Enhanced 16-Lead TSSOP or 8-Lead SO Package n Constant 1.25MHz Switching Frequency n Wide Operating Voltage Range: 3V to 25V n High Efﬁciency 0.09Ω Switch n 1.2V Feedback Reference Voltage n Uses Low Proﬁle Surface Mount Components n Low Shutdown Current: 15μA n Synchronizable to 2MHz n Current Mode Loop Control n Constant Maximum Switch Current Rating at All Duty Cycles.
n Available in 8-Lead SO and 16-Lead Thermally Enhanced TSSOP Packages.
