PALLV22V10 - Low-Voltage Zero Power 24-Pin EE CMOS Versatile PAL Device

Description

The PALLV22V10 is an advanced PAL® device built with low-voltage, high-speed, electricallyerasable CMOS technology.

The PALLV22V10Z provides low voltage and zero standby power.

At 30 µA maximum standby current, the PALLV22V10Z allows battery powered operation for an extended period.

Features

  • of the PALCE22V10. The PALLV2210Z is the low-voltage, zero-power version of the PALCE22V10. It has all the architectural features of the PALCE22V10. In addition, the PALLV22V10Z has zero standby power and an unused product term disable feature. The PALLV22V10 allows the systems engineer to implement a design on-chip by programming EE cells to configure AND and OR gates within the device, according to the desired logic function. Complex interconnections between gates, which previously required tim.

📥 Download Datasheet

Datasheet Details

Part number PALLV22V10
Manufacturer Lattice Semiconductor
File Size 378.81 KB
Description Low-Voltage Zero Power 24-Pin EE CMOS Versatile PAL Device
Datasheet download datasheet PALLV22V10 Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
PALLV22V10Z-25 Zero-Power 24-Pin EE CMOS Versatile PAL Device Advanced Micro Devices
PAL007 PAL007 ETC
PAL007 4 x 51W quad bridge car radio amplifier STMicroelectronics
PAL007A Power AMP Pioneer
PAL007E Power AMP Pioneer

Other Datasheets by Lattice Semiconductor

Part Number Description
PALLV22V10Z Low-Voltage (Zero Power) 24-Pin EE CMOS Versatile PAL Device
PALLV16V8-10JC Low Voltage/ Zero Power 20-Pin EE CMOS Universal Programmable Array Logic
PALLV16V8-10PC Low Voltage/ Zero Power 20-Pin EE CMOS Universal Programmable Array Logic
PALLV16V8-10SC Low Voltage/ Zero Power 20-Pin EE CMOS Universal Programmable Array Logic
PALLV16V8Z-20JI Low Voltage/ Zero Power 20-Pin EE CMOS Universal Programmable Array Logic

Full PDF Text Transcription

Click to expand full text
PALLV22V10 PALLV22V10Z COM'L: -7/10/15 IND: -15 IND: -25 PALLV22V10 and PALLV22V10Z Families Low-Voltage (Zero Power) 24-Pin EE CMOS Versatile PAL Device DISTINCTIVE CHARACTERISTICS x Low-voltage operation, 3.3 V JEDEC compatible x x x x x x x x x GENERAL DESCRIPTION The PALLV22V10 is an advanced PAL® device built with low-voltage, high-speed, electricallyerasable CMOS technology. The PALLV22V10Z provides low voltage and zero standby power. At 30 µA maximum standby current, the PALLV22V10Z allows battery powered operation for an extended period. The product terms are connected to the fixed OR array with a varied distribution from 8 to 16 across the outputs (see Block Diagram). The OR sum of the products feeds the output macrocell.
