LM185WH2-TLA1 - HD TFT LCD Module

Description

ABSOLUTE MAXIMUM RATINGS ELECTRICAL SPECIFICATIONS ELECTRICAL CHARACTERISTICS INTERFACE CONNECTIONS ITEM Page 1 2 3 4 5 6 6 8 11 14 15 16 17 18 19 24 27 28 28 28 29 29 29 30 30 30 31 31 31 31 y r a n i m i l e www.jxlcd.com www.jxlcd.com r P LVDS characteristics SIGNAL TIMING SPECIFICATIONS SIGNA

Features

  • Active screen size Outline Dimension Pixel Pitch Pixel Format Interface Color depth Luminance, white Viewing Angle (CR>10) Power Consumption Weight Display operating mode Surface treatments Color Gamut Ver. 0.4 18.51 inches (470.1mm) diagonal 430.4(H) x 254.6(V) x 9.7(D) mm(Typ. ) 0.10.
  • RGB(H)mm x 0.30(V)mm 1366 horizontal By 768 vertical Pixels. RGB stripe arrangement LVDS 1Port 16.7M colors 250 cd/m2 ( Center 1Point, typ) R/L 170(Typ. ), U/D 160(Typ. ) Total 12.82W(Typ. ), (3.60 W@VLCD , 9.22W.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
LM185 Adjustable Micropower Voltage References National Semiconductor
LM185-1.2 Micropower Voltage Reference Diode National Semiconductor
LM185-1.2 Micropower Voltage Reference Linear
LM185-1.2-N Micropower Voltage Reference Diode Texas Instruments
LM185-1.2QML Micropower Voltage Reference Diode Texas Instruments

Other Datasheets by LG Electronics

Part Number Description
LM185WH2-TLA3 HD TFT LCD
LM185WH2-TLC1 HD TFT LCD
LM185WH2-TLD1 HD TFT LCD Module
LM185WH2-TLE1 HD TFT LCD
LM185WH1-TLA1 LCD

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
LM185WH2 Liquid Crystal Display Product Specification SPECIFICATION FOR APPROVAL (◆) Preliminary Specification ( ) Final Specification Title BUYER MODEL y r a n i m i l e www.jxlcd.com www.jxlcd.com r P 18.5” HD TFT LCD SUPPLIER *MODEL SUFFIX General LM185WH2 TLA1 DATE APPROVED BY S.G. Hong / G.Manager / REVIEWED BY S.U. Byun / Manager [C] / Y.H. Hwang / Manager [M] H.S. Lee / Manager [P] / PREPARED BY D.K. Heo / Engineer LG Display Co., Ltd. *When you obtain standard approval, please use the above model name without suffix SIGNATURE DATE Please return 1 copy for your confirmation With your signature and comments. Product Engineering Dept. LG Display Co., Ltd Ver. 0.4 APR., 28, 2010 1 / 31 Free Datasheet http://www.datasheet4u.
