L3200A, L3200ACxxALxxA - COLOR MONITOR SERVICE MANUAL

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: L3200A, L3200ACxxALxxA. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number L3200A, L3200ACxxALxxA
Manufacturer LG
File Size 7.25 MB
Description COLOR MONITOR SERVICE MANUAL
Datasheet download datasheet L3200ACxxALxxA_LG.pdf
Note This datasheet PDF includes multiple part numbers: L3200A, L3200ACxxALxxA.
Please refer to the document for exact specifications by model.

L3200A Product details

Description

OF BLOCK DIAGRAM10 ADJUSTMENT 11 SERVICE OSD 13 TROUBLESHOOTING GUIDE 14 WIRING DIAGRAM 21 EXPLODED VIEW22 REPLACEMENT PARTS LIST 24 SCHEMATIC DIAGRAM 34 SPECIFICATIONS 1. LCD CHARACTERISTICS Type : TFT Color LCD Module Active Display Area : 31.51inches(800.4mm)diagonal Pixel Pitch : 170.25um x 510.75um x RGB Color Depth : 8-bit, 16,777,216 colors Electrical Interface : LVDS Size : 760mm (H) x 450 (D)x48 (D)mm Surface Treatment : Anti-Glare, Hard Coating(3H) Operating Mode : Normally Black
