DK100-B5 Datasheet (LEM) - DC Current transducer

DK100-B5, DC Current transducer

DC Current Transducer DK-B5 Split core transducer for the electronic measurement of DC current, with galvanic separation between the primary circuit and the secondary circuit.

0-5 V DC output voltage proportional to measured current.

IPN = 50 ..

200 A Electrical data Primary nominal current IPN (At) 50, 75, 100 100, 150, 200 Output voltage Types VOUT (V DC) 0-5 DK 100 B5 0-5 DK 200 B5 RoHS since date code August 2009 August 2009 UC Supply voltage RL Maximum load resistance VSL O

DK100-B5 Features

* DC measurement (magnitude only)

* Split core case

* Three jumper selectable ranges

* Industry standard 0-5 V DC unipolar voltage output

* Panel mounting

* Insulating plastic case recognized according to UL 94-V0. Advantages

* Large ape
