AAAF5050-MC-K12

The AAAF5050-MC-K12 is SMD LED designed by Kingbright.

Product Overview

Kingbright

Datasheet Details

Part number	AAAF5050-MC-K12
Manufacturer	Kingbright
File Size	810.00 KB
Description	SMD LED
Datasheet	AAAF5050-MC-K12-Kingbright.pdf
Additional preview pages of the AAAF5050-MC-K12 datasheet.

Product details

Description

An intelligent control LED light source that integrates the control circuit and RGB chips in a 5050 package for a complete control of pixel point Data protocol uses unipolar NRZ communication mode The control chip integrated in the LED enables a simple circuit, small size, and convenient installation Electrostatic discharge and power surge could damage the LEDs It is recommended to use a wrist band or anti-electrostatic glove when handling the LEDs All devices, equipments and machineries must b

Features

The control circuit and the LED share the same power source Intelligent protection against reverse connection Built-in electric reset and power lost reset circuit 256-level grayscale adjustable circuit Built-in signal reshaping circuit Cascade port transmission signal by single line Moisture sensitivity level: 3 Halogen-free RoHS compliant.
