RK73B2A, RK73B1E flat chip resistors

RK73B2A Description

RK73-RT flat chip resistors (anti-sulfuration) .

RK73B2A Features

* Excellent anti-sulfuration characteristic due to using high sulfuration-proof inner top electrode material
* Excellent heat resistance and weather resistance are ensured by the use of metal glaze thick film
* High stability and high reliability with the triple-layer structu

RK73B2A Applications

* and ratings Part Designation RK73B1E RK73H1E RK73B1J RK73H1J RK73B2A RK73H2A RK73B2B RK73H2B RK73B2E RK73H2E RK73BW2H RK73HW2H RK73BW3A RK73HW3A Power T. C. R. Rating (ppm/°C) Max. @ 70°C 0.063W 0.1W 0.125W 0.25W 0.5W 0.33W 0.5W 0.33W 0.75W 1W ±200 ±100 ±200 ±100 ±200 ±100 ±200 ±100 ±200 ±100 ±200 ±10

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: RK73B2A, RK73B1E. Please refer to the document for exact specifications by model.
datasheet Preview Page 2

Datasheet Details

Part number
RK73B2A, RK73B1E
Manufacturer
KOA
File Size
142.15 KB
Datasheet
RK73B1E_KOA.pdf
Description
flat chip resistors
Note
This datasheet PDF includes multiple part numbers: RK73B2A, RK73B1E.
Please refer to the document for exact specifications by model.
