K1500S Sidac

K1500S Description

JIEJIE MICROELECTRONICS CO., Ltd K0900S Series Sidac Rev.1.0 .
The sidac is a silicon bilateral voltage triggered switch with greater power-handling capabilities than standard diacs.

K1500S Features

* Excellent capability of absorbing transient surge
* Quick response to surge voltage (ns Level)
* Glass-passivated junctions
* High voltage lcmp ignitors ABSOLUTE MAXIMUM RATINGS (TA=25ºC, RH=45%-75%, unless otherwise noted) Parameter Symbol Sto

K1500S Applications

* High-voltage lamp ignitors
* Natural gas ignitors
* Gas oil ignitors
* High-voltage power supplies
* Xenon ignitors
* Overvoltage protector
* Pulse generators

📥 Download Datasheet

Preview of K1500S PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
K1500S
Manufacturer
JIEJIE
File Size
182.31 KB
Datasheet
K1500S-JIEJIE.pdf
Description
Sidac
