JCT855S 55A SCRs

JCT655/855 series of silicon controlled rectifiers, with high ability to withstand the shock loading of large current, provide high dv/dt rate with strong resistance to electromagnetic interference. They are especially recommended for use on solid state relay, motorcycle, power charger, T-tools etc.

JCT855S Features

* Symbol VDRM/ VRRM IT(RMS) IGT G(3) JCT655 600V 55A 10 - 50 mA JCT855 800V ABSOLUTE MAXIMUM RATINGS Parameter Storage junction temperature range Operating junction temperature range Repetitive peak off-state voltage(Tj=25℃) Repetitive peak reverse voltage(Tj=25℃) Non repetitive surge peak Off-s
