MB26S, MB22S - Surface Mount Schottky Bridge Rectifiers

Name: MB26S
SKU: MB26S-1378691

JGD

The MB26S by JGD is a Surface Mount Schottky Bridge Rectifiers. Below is the official datasheet preview.

Datasheet Details

Part number	MB26S, MB22S
Manufacturer	JGD
File Size	257.59 KB
Description	Surface Mount Schottky Bridge Rectifiers
Datasheet	MB22S-JGD.pdf
Note	This datasheet PDF includes multiple part numbers: MB26S, MB22S. Please refer to the document for exact specifications by model.
Additional preview pages of the MB26S datasheet.

Surge overload rating - 50 Amperes peak.
Ideal for printed circuit board.
Reliable low cost construction utilizing molded.
Glass passivated device.
Polarity symbols molded on body Mechanical Data.
Case : MBS, Molded Plastic.
Epoxy : Device has UL flammability classification 94V-0.
Mounting Position : Any.
Weight : 0.22 grams (approx. ).
Marking : Type Number MB22S THRU MB210S Surface Mount Schottky Bridge Rectifiers F B EL CA G H D 0~10° MB.
