JANSR2N7405 - 25A/ 100V/ 0.070 Ohm/ Rad Hard/ N-Channel Power MOSFET

Product Overview

Intersil Corporation

Datasheet Details

Part number	JANSR2N7405
Manufacturer	Intersil Corporation
File Size	44.88 KB
Description	25A/ 100V/ 0.070 Ohm/ Rad Hard/ N-Channel Power MOSFET
Datasheet	JANSR2N7405 Datasheet
Additional preview pages of the JANSR2N7405 datasheet.

Product details

Description

The Discrete Products Operation of Intersil Corporation has developed a series of Radiation Hardened MOSFETs specifically designed for commercial and military space applications.

Features

25A (Note), 100V, rDS(ON) = 0.070Ω.
Total Dose - Meets Pre-RAD Speciﬁcations to 100K RAD (Si).
Single Event - Safe Operating Area Curve for Single Event Effects - SEE Immunity for LET of 36MeV/mg/cm2 with VDS up to 80% of Rated Breakdown and VGS of 10V Off-Bias.
Dose Rate - Typically Survives 3E9 RAD (Si)/s at 80% BVDSS - Typically Survives 2E12 if Current Limited to IDM.
Photo Current - 7.0nA Per-RAD(Si)/s Typically.
Neutron - Maintain Pre-.
