ISL29004 - Light-to-Digital Output Sensor

Intersil Corporation

Datasheet Details

Part number	ISL29004
Manufacturer	Intersil Corporation
File Size	287.79 KB
Description	Light-to-Digital Output Sensor
Datasheet	ISL29004_IntersilCorporation.pdf

Range select via I2C - Range1 = 1000Lux - Range2 = 4000Lux - Range3 = 16,000Lux - Range4 = 64,000Lux.
Human eye response (540nm peak sensitivity).
Temperature compensated.
16-bit resolution.
Adjustable resolution: up to 65 counts per Lux.
User-programmable upper and lower threshold interrupt.
Simple output code, directly proportional to Lux.
50Hz/60Hz rejection.
2.5V to 3.3V supply.
8 Ld ODFN (3mmx3mm).
