HA-2626 - 100MHz/ High Input Impedance/ Very Wideband/ Uncompensated Operational Amplifiers

Intersil (Renesas)

Key Features

Gain Bandwidth Product (AV ≥ 5).
. . . 100MHz.
High Input Impedance.
. 500MΩ.
Low Input Bias Current.
. . . . 1nA.
Low Input Offset Current.
. . 1nA.
Low Input Offset Voltage.
0.5mV.
High Gain.
150kV/V.
Slew Rate.

HA-2626 100mhz/ high input impedance/ very wideband/ uncompensated operational amplifiers by Intersil (Renesas) - Datasheet Preview

Datasheet Details

Part number	HA-2626
Manufacturer	Intersil (Renesas)
File Size	120.49 KB
Description	100MHz/ High Input Impedance/ Very Wideband/ Uncompensated Operational Amplifiers
Datasheet	HA-2626 Datasheet

📁 Similar Datasheet

Part Number	Description	Manufacturer
HA-2620	Uncompensated Operational Amplifiers	Intersil
HA-2620	Uncompensated Operational Amplifiers	Renesas
HA-2625	Uncompensated Operational Amplifiers	Intersil
HA-2625	Uncompensated Operational Amplifiers	Renesas
HA-2600	High Input Impedance Operational Amplifier	Intersil

Other Datasheets by Intersil (Renesas)

Part Number	Description
HA-2605	12MHz/ High Input Impedance Operational Amplifiers
HA-2404	40MHz/ PRAM Four Channel Programmable Amplifiers
HA-2405	40MHz/ PRAM Four Channel Programmable Amplifiers
HA-2406	30MHz/ Digitally Selectable Four Channel Operational Amplifier
HA-2444	50MHz/ Selectable/ Four Channel Video Operational Amplifier

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text

HA-2620, HA-2625 Data Sheet November 1999 File Number 2903.4 100MHz, High Input Impedance, Very Wideband, Uncompensated Operational Ampliﬁers HA-2620/2625 are bipolar operational ampliﬁers that feature very high input impedance (500MΩ, HA-2620) coupled with wideband AC performance. The high resistance of the input stage is complemented by low offset voltage (0.5mV, HA-2620) and low bias and offset current (1nA, HA-2620) to facilitate accurate signal processing. Input offset can be reduced further by means of an external nulling potentiometer. The 100MHz gain bandwidth product (HA-2620/2625 are stable for closed loop gains greater than 5), 35V/µs slew rate and 150kV/V open loop gain enables HA-2620/2625 to perform high gain ampliﬁcation of very fast, wideband signals.
