CD40208BMS - CMOS 4 x 4 Multiport Register

Name: CD40208BMS
SKU: CD40208BMS-108833

Intersil Corporation

📥 Download Datasheet

CD40208BMS Datasheet Preview — Preview of CD40208BMS PDF

Datasheet Details

Part number	CD40208BMS
Manufacturer	Intersil Corporation
File Size	130.90 KB
Description	CMOS 4 x 4 Multiport Register
Datasheet	CD40208BMS_IntersilCorporation.pdf

CD40208BMS Product details

Description

The CD40208BMS is a 4 x 4 multiport register containing four 4-bit registers, write address decoder, two separate read address decoders, and two 3-state output buses.

Features

High Voltage Types (20V Rating) One Input and Two Output Buses Unlimited Expansion in Bit and Word Directions Data Lines have Latched Inputs 3-State Outputs Separate Control of Each Bus, Allowing Simultaneous Independent Reading of any of Four Registers on Bus A and Bus B and Independent Writing Into any of the Four Registers 100% Tested for Quiescent Current at 20V Standardized, Symmetrical Output Characteristics 5V, 10V and 15V Parame.
