CA5160M96, CA5 - 4MHz/ BiMOS Microprocessor Operational Amplifiers with MOSFET Input/CMOS Output

Intersil Corporation

Datasheet Details

Part number	CA5160M96, CA5
Manufacturer	Intersil Corporation
File Size	656.08 KB
Description	4MHz/ BiMOS Microprocessor Operational Amplifiers with MOSFET Input/CMOS Output
Datasheet	CA5-160.pdf
Note	This datasheet PDF includes multiple part numbers: CA5160M96, CA5. Please refer to the document for exact specifications by model.

Refer to the block diagram of the CA5160 CMOS Operational Amplifier.

MOSFET Input Stage - Very High ZI; 1.5TΩ (1.5 x 1012Ω) (Typ) - Very Low II; at 15V Operation.
. . . 5pA (Typ) at 5V Operation.
. . . 2pA (Typ).
Common-Mode Input Voltage Range Includes Negative Supply Rail; Input Terminals Can be Swung 0.5V Below Negative Supply Rail.
CMOS Output Stage Permits Signal Swing to Either (or Both) Supply Rails.
CA5160 Has Full Military Temperature Range Guaranteed Specifications for V+ = 5V.
