IDT54FCT162543CT Datasheet Preview — Preview of IDT54FCT162543CT PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number: IDT54FCT162543CT
Manufacturer: Integrated Device Technology
File Size: 127.73 KB
Datasheet: IDT54FCT162543CT_IntegratedDeviceTechnology.pdf
Description: FAST CMOS 16-BIT LATCHED TRANSCEIVER

IDT54FCT162543CT Product details

Description

The FCT16543T/AT/CT/ET and FCT162543T/AT/CT/ET 16-bit latched transceivers are built using advanced dual metal CMOS technology.

Features

FCT16543T/AT/CT/ET:.
High drive outputs (-32mA IOH, 64mA IOL).
Power off disable outputs permit “live insertion”.
Typical VOLP (Output Ground Bounce) < 1.0V at VCC = 5V, TA = 25°C.
Features for FCT162543T/AT/CT/ET:.
Balanced Output Drivers: ±24mA (commercial), ±16mA (military).
Reduced system switching noise.
Typical VOLP (Output Ground Bounce) < 0.6V at VCC = 5V,TA = 25°C.
