CYPD3171 - CCG3PA Consumer USB Type-C port controller

Description

EZ-PD™ CCG3PA is Infineon’s highly integrated USB Type-C port controller that complies with the latest USB Type-C and PD standards and is targeted for PC power adapters, mobile chargers, car chargers, and power bank applications.

Features

  • Type-C support and USB PD support - Supports USB PD Revision 3.1 including programmable power supply (PPS) mode - Configurable resistors RP and RD - Supports one USB Type-C port and one Type-A port.
  • 2x legacy/proprietary charging blocks - Supports QC 4.0, Apple charging 2.4A, AFC, BC 1.2 - Integrates all required terminations on DP/DM lines.
  • Integrated voltage (VBUS) regulation and current sense amplifier - Analog regulation of secondary side feedback node (direct fee.

📥 Download Datasheet

Datasheet Details

Part number CYPD3171
Manufacturer Infineon
File Size 413.62 KB
Description CCG3PA Consumer USB Type-C port controller
Datasheet download datasheet CYPD3171 Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
CYPD3120 USB Type-C Port Controller Cypress Semiconductor
CYPD3121 USB Type-C Port Controller Cypress Semiconductor
CYPD3122 USB Type-C Port Controller Cypress Semiconductor
CYPD3123 USB Type-C Port Controller Cypress Semiconductor
CYPD3125 USB Type-C Port Controller Cypress Semiconductor

Other Datasheets by Infineon

Part Number Description
CYPD3174 CCG3PA Consumer USB Type-C port controller
CYPD3175 CCG3PA Consumer USB Type-C port controller
CYPD2803 CMG2 USB Type-C EMCA controller
CYPD6129 CCG6_CFP USB-C Power Delivery (PD) controller
CYPD6139 CCG6_CFP USB-C Power Delivery (PD) controller

Full PDF Text Transcription

Click to expand full text
CYPD3171, CYPD3174, CYPD3175 EZ-PD™ CCG3PA Consumer USB Type-C port controller General description EZ-PD™ CCG3PA is Infineon’s highly integrated USB Type-C port controller that complies with the latest USB Type-C and PD standards and is targeted for PC power adapters, mobile chargers, car chargers, and power bank applications. In such applications, CCG3PA provides additional functionalities and BOM integration advantages. CCG3PA uses Infineon’s proprietary M0S8 technology with a 32-bit Arm® Cortex®-M0 processor, 64-KB flash, a complete Type-C USB PD transceiver, all termination resistors required for a Type-C port, integrated feedback control circuitry for voltage (VBUS) regulation, and system-level ESD protection. It is available in 24-pin QFN and 16-pin SOIC packages.
