TDA16834 - Off-Line SMPS Controller

Download the TDA16834 datasheet PDF. This datasheet also covers the TDA16831-4 variant, as both devices belong to the same off-line smps controller family and are provided as variant models within a single manufacturer datasheet.

Description

The TDA 16831-4 is a current mode pulse width modulator with integrated sense CoolMOS transistor.

It fulfills the requirements of minimum external control circuitry for a flyback application.

Features

  • PWM controller + sense CoolMOS attached in one compact package.
  • 600 V avalanche rugged CoolMOS.
  • Typical RDSon = 0.5 3.5 Ω at Tj = 25 °C.
  • Only 4 active Pins.
  • Standard DIP-8 Package for Output Power ≤40 W.
  • Only few external components required.
  • Low start up current.
  • Current mode control.
  • Input Undervoltage Lockout.
  • Max. Duty Cycle limitation.
  • Thermal Shutdown.
  • Modulated Gate Drive for low.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (TDA16831-4_InfineonTechnologies.pdf) that lists specifications for multiple related part numbers.

Datasheet Details

Part number TDA16834
Manufacturer Infineon
File Size 317.08 KB
Description Off-Line SMPS Controller
Datasheet download datasheet TDA16834 Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
TDA16831 Off-Line SMPS Controller Infineon
TDA16822 Off-Line Current Mode Controller Infineon
TDA16847 Controller Infineon
TDA16847-2 Controller Infineon
TDA16850-2 Free running and synchronized SMPS Controller Infineon Technologies Corporation

Other Datasheets by Infineon

Part Number Description
TDA16831-4 Off-Line SMPS Controller
TDA16832 Off-Line SMPS Controller
TDA16833 Off-Line SMPS Controller
TDA16846 (TDA1684x-x) Controller
TDA16846-2 (TDA1684x-x) Controller

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
Off-line SMPS Controller with 600 V Sense CoolMOS on Board Preliminary Data Overview Features • PWM controller + sense CoolMOS attached in one compact package • 600 V avalanche rugged CoolMOS • Typical RDSon = 0.5 ... 3.5 Ω at Tj = 25 °C • Only 4 active Pins • Standard DIP-8 Package for Output Power ≤40 W • Only few external components required • Low start up current • Current mode control • Input Undervoltage Lockout • Max.
