IRF4905 - P-Channel MOSFET Transistor

Description

design,provide the designer with an extremely efficient and reliable device for use in a wide variety of applications.

ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE VDSS Drain-Source Voltage -55 VGS Gate-Source

Features

  • Static drain-source on-resistance: RDS(on)≤0.02Ω.
  • Enhancement mode:.
  • 100% avalanche tested.
  • Minimum Lot-to-Lot variations for robust device performance and reliable operation.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
IRF4905 Power MOSFET International Rectifier
IRF4905 -55V P-Channel MOSFET UMW
IRF4905L Power MOSFET International Rectifier
IRF4905L P-Channel MOSFET INCHANGE
IRF4905LPBF HEXFET Power MOSFET International Rectifier

Other Datasheets by Inchange Semiconductor

Part Number Description
IRF420 N-Channel MOSFET Transistor
IRF421 N-Channel MOSFET Transistor
IRF422 N-Channel MOSFET Transistor
IRF423 N-Channel MOSFET Transistor
IRF430 N-Channel MOSFET Transistor

Full PDF Text Transcription

Click to expand full text
isc P-Channel MOSFET Transistor IRF4905,IIRF4905 ·FEATURES ·Static drain-source on-resistance: RDS(on)≤0.02Ω ·Enhancement mode: ·100% avalanche tested ·Minimum Lot-to-Lot variations for robust device performance and reliable operation ·DESCRIPTION ·Combine with the fast switching speed and ruggedized device design,provide the designer with an extremely efficient and reliable device for use in a wide variety of applications. ·ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE VDSS Drain-Source Voltage -55 VGS Gate-Source Voltage ±20 ID Drain Current-Continuous -74 IDM Drain Current-Single Pulsed -260 PD Total Dissipation @TC=25℃ 200 Tj Max.
